SG Series

SG400

High speed SCARA robot with 400 mm reach

Yaskawa Ireland Robotics Yaskawa Robots Pick & Place SG Series SG400

product_overview

Designed for fast operating performance, the SG400 4-axis SCARA robot is ideal for increasing throughput for small part processing applications. It can handle part weights up to 3 kg. Highly precise and repeatable, the SG400 is well-suited for assembly and sortation processes needing short cycle times, as well as multi-process systems requiring pick-and-place capability. A compact body design with small footprint minimizes mounting space and enables easy integration with existing automation.

The SG400 is well suited for pick&place and smart part feeding in assembly.

product_technical_details

  • Number of Axis
  • 4
  • Payload
  • 3 kg
  • Max Working Range
  • 400 mm
  • Repeatability
  • 0.01 mm
  • Weight
  • 14 kg
  • Power Supply
  • 1 kVA
  • Maximum Speed S Axis
  • 740 °/s
  • Maximum Speed L Axis
  • 800 °/s
  • Maximum Speed U Axis
  • 1200 mm/s
  • Maximum Speed R Axis
  • 3000 °/s
  • Maximum Speed B Axis
  • x No
  • Maximum Speed T Axis
  • x No
  • Mounting Options
  • Floor
  • Further Specifications
  • x No
